Engineering Menu

Intro

The engineering menu contains panel settings like, Brightness control and dim/sleep time. You can also find other settings like, expert mode and global Invert pan/tilt.

It can be accessed in different ways based on the panel, and chosen configuration.

How do I know which method my configuration is using?

 Here we have listed the different 'panel configurations' that have the engineering menu.

Remember this is a list of configurations. So the specific panels named here, only have access to the engineering menu, when the loaded configuration contains such menu. This also means that you will find panels not named here, that can also access an engineering menu. To find the exact method used in your panel config, you can navigate the list here, and try methods that is in correspondence with your panel type.

Method 1 - Camera selector

This technique is used for panel configurations that has a camera page button or a combo menu button, that both cycle camera pages and the menus.

How to activate

Press and hold the top edge of the 'Page' button  A  for a few seconds

Examples of models using this method:

Listed here is 4 panels that have support for a configuration, that have an engineering menu accessible the same way. Remember this is just examples, and that this method is not exclusive to these 4 panels.

PTZ Wiz

PTZ Fly


Rack Control Uno

Inline 22


Method 2 - PTZ Pro

This technique is used for PTZ Pro only.

How to activate

Press and hold U4  A  for a few seconds

Examples of models using this method:

This method is exclusive to the panel showed below

PTZ Pro

Method 3 - PTZ Extreme

This technique is used for PTZ Extreme only.

How to activate

Press and hold U4  A  for a few seconds

Examples of models using this method:

This method is exclusive to the panel showed below

PTZ Extreme


Method 4 - RCP

This technique is used for every RCP panel (with config: "RCP - Generic PTZ Control").

How to activate

Step 1) Press and hold the 'Shift' button  A
Step 2) Now press the 'Panel lock' button  B  to enter the engineering menu

Examples of models using this method:

Remember this is just examples, and that this method is not exclusive to this RCP panel only, but all RCP models, with the config "RCP - Generic PTZ Control".

RCPv2


Method 5 - MEGA Panel

This technique is used on panel MKT1B and MKT1A

How to activate

Step 1) Press 'Menu'  A  to make the settings button appear
Step 2) Press 'settings'  B  to enter the engineering menu

Examples of models using this method:

This method is not exclusive to the panel showed below, but also MKT1A.

MKT1B


Method 6 - Switcher Selector

This technique is used for panel configurations in the switcher class.

How to activate

Step 1) Press 'Shift'  A  to make the FTB button light green
Step 2) Press 'FTB'  B  to enter the engineering menu

Examples of models using this method:

Listed here is 3 panels that have support for a configuration, that have an engineering menu accessible the same way. Remember this is just examples, and that this method is not exclusive to these 3 panels.

Airfly


Airfly Pro


Master Key One


Method 7 - Kairos

This technique is specific for our Kairos configuration for the Master Key One V2 (Blue pill inside)

How to activate

Step 1) Press and hold the button marked  A
Step 2) Now press the button marked   B  to enter the engineering menu

Examples of models using this method:

This method is exclusive to the Kairos configuration on the panel showed below

Master Key One V2
